45 replies to this topic

[superUPer]

well, here's my finished product! I can't believe it actually works. Started with an 02 mxzx 440, figured i should get a bigger motor. I found a 98 670 (yes it's a 670 not 583). made some plans, decided to move to CO for the winter, so I'd need a bigger track. I managed to fit a 151 x 16 x 2 with some work, used an 05 skid. put a rev seat on for fun (super sweet upgrade!) umm, yeah, a lot of work and waaay to much money later, here it is

Attached Files

•  P1000689.JPG   64.86K   59 downloads

[superUPer]

custom snow flap

Attached Files

•  P1000683.JPG   68.84K   14 downloads

[superUPer]

SUPER custom tunnel extension... had my little brother build one in his shop class, but that was for a 136, plans changed to 151, buddy had short extension, owed me money, yadda yadda ding dong, that's what i have. Cool billets, ported the track...

Attached Files

•  P1000688.JPG   62.21K   15 downloads

[superUPer]

should have taken off that registration sticker before doing the brackets...here's the motor. deleted oil injection

Attached Files

•  P1000686.JPG   63.15K   15 downloads

[superUPer]

keeping the stock air box took some work... pvc elbows with BIG coolant hose and electrical tape works good!

Attached Files

•  P1000687.JPG   58.88K   17 downloads

[mike_1786]

Looks sharp, good job, let us know how she rides.

[superUPer]

did some custom venting because the air box was getting choked by the hood... Cyberdyne temp guage, yes I used the tether as a switch (pull it off, guage turns on, yay!)

Attached Files

•  P1000684.JPG   69.61K   10 downloads

[superUPer]

this is a beauty! I needed DC to run the temp gauge, so i tried building my own rectifier with parts from radioshack... didn't work. I could only find one battery pack small enough ($75 no thank you) so i built my own from double A's

Attached Files

•  P1000685__2_.JPG   69.35K   9 downloads

[superUPer]

So there it is, not sure if i should be embarrassed or proud, but i can say this thing rips! comments, suggestions, insults, post em all!

if you want the same machine:

02 mxzx chassis
ported 98 670
440 wiring harness, heavily modified
oil injection delete
custom motor plate
custom intake
re routed coolant hoses
440 coolant bottle and small oil bottle
new exhaust exit hole
cut the sway bar out
handle grip warmers
8 tooth extroverts
tons of rivet grinding and re riveting
new rear suspension brackets (I broke these once already, needed extra rivets when mounted on the outside of the tunnel)
drop front mounting holes down

got lucky and the clutching is great without touching it! probably could be improved though
Just for the record I left the small 440 coolers in and the motor runs at a consistant 116 degrees.

that about does it. Thanks dootalkers for all your help and parts. Without dootalk this definately would not have happened.

Attached Files

•  P1000690.JPG   64.65K   8 downloads

[98formula500]

WOW!! thats is sure a sweet sled the rev seat on there looks wicked i really wanna put one on my s-chassie formula!!

[superUPer]

oh I should point out the two sleds in the backround, both polaris guys wrenching away!

[Maniac]

Haha! Cool stuff man. Good work.

[mxzmadness]

NICE ride man

[Coryp1]

darn, real nice sharp looking sled!

[MxzMbrp700]

This would have been a cool build too follow....shouldve posted pics Nice sled !
